JIH - 20 CE Type - Semi auto Rotary Sawing Machine Series

JIH - 20 CE Type - Sawing Machine Series
JIH - 20 CE Type - Sawing Machine Series
  • To operate the machine, simply treadle on the foot switch, the machine will automatically perform clamping and cutting for convenient operation.
  • Concealed saw blade performs upward cutting. Single or multiple work pieces can be cut simultaneously.
  • While cutting, the oil mist splashes automatically for cooling and lubrication.
  • Cutting feed is driven by a hydraulic pneumatic combination cylinder for extremely stable cutting speed.
  • The machine cabinet painting is baked by high temperature of 200 degree ( Powder coating ) for resisting bumping without paint peeling off.
  • The machine permits ± 0 ~ 45 degree cutting.



Model

JIH-20 TYPE

Cutting Angle

+45° ~ 0° ~ -45°

Saw blade Sizes

20"x1"bore

Spindle Speed

2,800 R.P.M.(60 HZ)

Motor

7.5 HP

Air Pressure

4-6 kgs/cm²

Table Area

772 x 386 mm

Table Height Form Floor

875mm

Net/Gross Weight

500 / 610kgs

Machine Dimensions
( LxWxH )

1,200x1,090x1,780mm

Packing Dimensions
( LxWxH )

1,320x1,210x1,980mm

*We reserve the rights to modify above specification without notice.

Optional:Automatic Rotary Angle,JIH-16R,JIH-20R,JIH20 24R,JIH-20 30R,JIH-20 36R

  • CE Standard•Infeed,Outfeed Roller Table•Chip Collector•Horizontal Clamp•Horizontal Feeding•Automatic Rotary Angle
    •With Auto3000 for Automatic Positioning, Automatic Feeding(Push), Automatic Rotary Angle, Automatic Cutting •Saw Blade

Aluminum, brass, heat sink, PVC, plastic steel, bakelite, acrylic plastic, teflon, honeycomb board and other non-ferrous metals.
