JIH-2024 / 2030/ 2036 Type - Semi auto Rotary Sawing Machine Large Model Series
- To operate the machine, simply treadle on the foot switch, the machine will automatically perform clamping and cutting for convenient operation.
- Concealed saw blade performs upward cutting. Single or multiple work pieces can be cut simultaneously.
- While cutting, the oil mist splashes automatically for cooling and lubrication.
- Cutting feed is driven by a hydraulic pneumatic combination cylinder for extremely stable cutting speed.
- The machine cabinet painting is baked by high temperature of 200 degree ( Powder coating ) for resisting bumping without paint peeling off.
- The machine permits ± 0 ~ 45 degree cutting.
Standard Equipment
24'' saw blade x 1pc、Handle for changing saw blade
Model | JIH-2024 | JIH-2030 (Hydraulic feeding) | JIH-2036(Hydraulic feeding) |
Cutting Angle | +45° ~ 0° ~ -45° | +45° ~ 0° ~ -45° | +45° ~ 0° ~ -45° |
Saw Blade Sizes | 24"x1"bore | 30"x50mm bore | 36"x50 mm bore |
Spindle Speed | 1,800 R.P.M. | 1,200R.P.M. | 1,000R.P.M. |
Motor | 7.5 HP | 10 HP | 10 HP |
Air Pressure | 4-6 kgs/cm² | 4-6 kgs/cm² | 4-6 kgs/cm² |
Table Area | 896 x 448mm | 1,080 x 540mm | 1,256 x 628mm |
Table Height Form Floor | 920mm | 1,070mm | 1,220mm |
Net/Gross Weight | 800 / 920kgs | 1,300 / 1,500 kgs | 1,800 / 2,300 kgs |
Machine Dimensions | 1,480x1,350x2,100mm | 1,660x1,400x2,210mm | 1,770x1,580x2,520mm |
Packing Dimensions | 1,600x1,470x2,260mm | 1,780x1,520x2,300mm | 1,900x1,700x2,230mm |
*We reserve the rights to modify above specification without notice.
Automatic Rotary Angle,JIH-16R,JIH-20R,JIH20 24R,JIH-20 30R,JIH-20 36R
- CE Standard•Infeed, Outfeed Roller Table•Chip Collector•Horizontal Clamp•Horizontal Feeding•Automatic Rotary Angle
- With Auto3000 for Automatic Positioning,Automatic Feeding(Push),Automatic Rotary Angle,Automatic Cutting •Saw Blade
Aluminum, brass, heat sink, PVC, plastic steel, bakelite, acrylic plastic, teflon, honeycomb board and other non-ferrous metals..
